The Core Test Wrapper Handbook: Rationale and Application of IEEE Std. 1500™

di Francisco da Silva (Autore)

Teresa McLaurin (Autore)

Tom Waayers (Autore)

Springer-Verlag New York Inc., 2014

In the early to mid-1990's while working at what was then Motorola Se- conductor, business changes forced my multi-hundred dollar microprocessor to become a tens-of-dollars embedded core. I ran into first hand the problem of trying to deliver what used to be a whole chip with something on the order of over 400 interconnect signals to a design team that was going to stuff it into a package with less than 220 signal pins and surround it with other logic. I also ran into the problem of delivering microprocessor specification verifi- tion – a microprocessor is not just about the functions and instructions included with the instruction set, but also the MIPs rating at some given f- quency. I faced two dilemmas: one, I could not deliver functional vectors without significant development of off-core logic to deal with the reduced chip I/O map (and everybody's I/O map was going to be a little different); and two, the JTAG (1149. 1) boundary scan ring that was around my core when it was a chip was going to be woefully inadequate since it did not support - speed signal application and capture and independent use separate from my core. I considered the problem at length and came up with my own solution that was predominantly a separate non-JTAG scan test wrapper that supported at-speed application of launch-capture cycles using the system clock. But my problems weren't over at that point either.

• Autore: Francisco da Silva, Teresa McLaurin, Tom Waayers
• Editore: Springer-Verlag New York Inc.
• Collana: Frontiers in Electronic Testing
• Anno: 2014
• Rilegatura: Paperback / softback
• Pagine: 276 p.
• Dimensioni: 235 x 155 mm
• EAN: 9781489987693

Testo in English
