Planar Circuits for Microwaves and Lightwaves

di T. Okoshi (Autore)

Springer-Verlag Berlin and Heidelberg GmbH & Co. KG, 2011

Until recently, three principal classes had been known in the electrical cir­ cuitry. They were as follows: 1) The lumped-constant circuit, which should be called a zero-dimensional circuit, in the sense that the circuit elements are much smaller in size as compared with the wavelength in all three spatial directions. 2) The distributed-constant circuit, which should be called a one-dimensional circuit, in the sense that the circuit elements are much smaller than the wavelength in two directions but comparable to the wavelength in one di­ rection. 3) The waveguide circuit, which should be called a three-dimensional circuit, in the sense that the circuit elements are comparable to the wavelength in all three directions. The principal subject of this book is the analysis and design (synthesis) theories for another circuit class which appeared in the late 1960s and became common in the 1970s. This new circuit class is 4) the planar circuit, which should be called a two-dimensional circuit, in the sense that the circuit elements are much smaller in size as compared with the wavelength in one direction, but comparable to the wavelength in the other two directions.

• Autore: T. Okoshi
• Editore: Springer-Verlag Berlin and Heidelberg GmbH & Co. KG
• Collana: Springer Series in Electronics and Photonics
• Anno: 2011
• Rilegatura: Paperback / softback
• Pagine: 202 p.
• Dimensioni: 235 x 155 mm
• EAN: 9783642700859

Testo in English
